Technical Specifications - Topline Rear Mono Shock (2016-Current)
Product Overview:
- Year: 2016-Current
- Product Group: Topline
- Shock Type: Rear Mono Shock
- Product Type: External Reservoir On Hose Gas Shock
- ABE: Not Applicable
Dimensions:
- Length: 275-285 mm
- Top Diameter: 12x35 mm
- Bottom Diameter: 12x60 mm
- Spring Dimensions: 46-150-140 mm
- Piston Size: 36 mm
- Shaft Size: 16 mm
Adjustability Features:
-
Compression Adjustable:
- Description: Controls the compression stage of shock absorbers and springs, allowing for fast or slow movements.
- Adjustment: Step-wise adjustability with 30 settings.
-
Thread Spring Preload:
- Description: Enables fine-tuning of spring tension through a threaded cylindrical shock absorber design.
- Adjustment: Users can turn the preload using an adjustable spring screw; a provided bolt secures the ring in position.
-
Rebound Adjustable:
- Description: Controls the recovery speed of the shock absorber, offering customization based on driver preferences.
- Components: Volume control knob, needle shaft, Free Bleed oil through hole.
- Adjustment: Time adjustment dial for precise customization.
-
Length Adjustable:
- Description: Provides flexibility by allowing an increase in the length of the shock absorber.
- Options: Two types - upgradable to 10 mm or adjustable within a range of /- 5 mm.
Rebound Adjustable is to control the recovery of the shock absorber. Fast or slow depending on driver needs. It is designed to have a volume control knob needle shaft Free Bleed oil through hole and the knob Rebound is designed to sense the adjusted time adjustment dial.
LENGTH ADJUSTABLE
Adjustable length. It helps increase the length of the shock absorber. The two types can be upgraded to 10 mm or adjustable lengths /- 5 mm.
