- Hand adjustable bypass valves with 28 detented settings at quarter turn increments for precise suspension tuning
- Bypass tubes are replaceable in the event of damage
- Internal “Bump Zone” increases damping force to provide more control as the shock approaches full compression
- Remote reservoir design improves heat dissipation to reduce shock fade during prolonged use
- Premium grade 5WT shock oil for consistent suspension damping along a wide temperature range
- One piece digressive piston design with vehicle specific valving for unsurpassed performance and ride quality on and off-road
- 7/8” diameter induction hardened, chrome plated shock shaft
- PTFE lined spherical bearings and application specific mounting hardware
- 6061 aircraft grade aluminum CNC machined components
- CAD plated, precision machined 1026 DOM steel shock body for maximum durability and corrosion resistance
- 100% Rebuildable
- 100% Revalveable
- ICON's Bypass Valve technology allows adjustment of compression and rebound damping with high resolution across the entire adjustment range
Additional Attributes:
- GTIN: 00840103404776
- 30: Yes
- 40: Yes
- Lower Mount Type: EYELET
- Upper Mount Type: EYELET
- Boot Included: NO
- 51: Yes
- Tube Outside Diameter: 2.5
- Shock Absorber Rod End Measuring Point: CENTER OF EYELET
- Shock Absorber Body End Measuring Point: CENTER OF EYELET
- Bore Diameter: 2.25
- External Reservoir: Yes
Packaging:
- Quantity of Each: 1.0
- Package UOM: EA
- Dimension: x x inches
